Tractor Model		AT5390F E1	AT5330F E1
Engine	Model	E3CDT (with Turbo)	E3CD
	No. of cylinders	3	3
	Displacement, L	1.498	1.498
	Out-put Net kW(hp)	29.85(40.0)	25.4(34.0)
	Rated Engine revolution, min^-1		2600
	Fuel Tank capacity, L		40
	Air cleaner		Double element
	Battery		55B24R
Transmission	Main Clutch		Dry, Single
	Main Shift		F3/R1
	Sub Shift		3
	No. of speed		F9/R3
	Lever Position	Main Shift	Side
		Sub Shift	Side
PTO	Rear PTO No. of Speed		2
	Revolution, mm-1		690x820
	Lever Position		Side
Travelling Speed	Forward, km/h	1.89 - 21(24)	1.71 - 19.8(21.7)
	Reverse, km/h	2.41 - 13.8	2.18 - 12.4(21.7)
Tyre	Front	8 - 16	7 - 16
	Rear	13.6 - 24	11.2 - 24
Front Axie	Power Steering		Intergral
	Front Bumper		Standard
Hydraulics	Lift capacity Link et, kgf		1,270
	24¡¨be, kgf		1,150
	Pump capacity Main, L/min		33.6
	Sub. L/min		18.1
	Oil Flow, L/min		51.7
	Position Control		Standard
	Draft Control		Option
	Aux. Valve		Option
3P Linkage	Type		Cat I
	Couping devise		Fixed Drawbar
Electric	Head Lights		45/40W
	Turning Signal/Hazard/Tall Lights		Standard
	Fuel/Techno meter		Standard
	Water temperature		Standard
Exterior	Floor shape		Semi Flat
	Floor mount		Floating mount
	Floor mat		Standard
	Seat		Standard(w/Spring)
	Engine hood		Tilt Up
Dimensions	Overall Length, mm		3,120(3P)
	Overall Width, mm		1,455
	Overall Height, mm	1,530(at Seat)	1,510(at Seat)
	Wheel base, mm		1,770
	Tread Front, mm	1,150(at Seat)	1,095
	Tread Rear, mm		1,100
	Min Ground clearance, mm	380	355
	Weight, kg	1,260	1,230

Tractor Model		NT536	NT540
DIMENSION
Overall length, mm		3060 (3P)	3060 (3P)
Overall width, mm		1455	1455
Overall height, mm		1495	1520
Wheel base, mm		1650	1650
Tread	Front, mm	1095	1150
Tread	Rear, mm	1100	1100
Min. height from ground, mm		375	400
Weight, kg		1235	1260
ENGINE
Model		E3CG-D	E3CG-TD
Number of cylinders		3	3
Displacement, L		1.647	1.647
Gross output, KW(PS)		26.6(36.2)	29.4(40.0)
Rated speed, min^-1		2700	2700
Fuel control system		Direct injection	Direct injection + Turbo Charger
Fuel tank capacity, L		43	43
TRANSMISSION
Main clutch		Single dry clutch	Single dry clutch
Gear shift	Shuttle	Synchro shuttle	Synchro shuttle
	Main gear speed	4	4
	Sub gear speed	2	2
No. of speed		F8/R8	F8/R8
Lever position	Main gear shift position	Center	Center
	Sub gear shift position	Side	Side
	Synhro shuttle position	Column	Column
Clutch Type	No. of speed	2	2
	Rotation speed (min^-1)	540/750	540/750
	PTO lever position	Side	Side
REAR AXLE
Diff lock		Pedal (Right)	Pedal (Right)
Braking system		Wet disc	Wet disc
Brake pedal type		2 pedal (Right)	2 pedal (Right)
Parking brake		STD (hook type)	STD (hook type)
Max speed	Forward (kw/h)	1.85-21.9(24.1)	1.85-21.9(24.1)
Max speed	Reverse (kw/h)	1.7-21.5	1.7-21.5
TIRE
Agricultural	Front wheel	8-16	8-16
Agricultural	Rear wheel	12.4-24	13.6-24
FRONT AXLE
Driving system		4WD/2WD	4WD/2WD
Steering system		integral	integral
Turning radius		2.4 (w/B)	2.4 (w/B)
HYDRAULIC
Hydraulic power	Ball end (kgf)	1000	1000
	24 inches (kgf)	810	810
	Main (L/min)	32.5	32.5
Pump discharge rate		50	50
Position control		STD	STD
Draft control		x	x
Auxiliary hydraulic valve / Standard (Max)		Opt x2	Opt x2
3 POINT LINKAGE
3P Linkage	Category	1	1
3P Linkage	Lower link	Ball End	Ball End
Rear hitch		Thai hitch	Thai hitch
EXTERIOR
Floor		Convex floor	Convex floor
Seat base		Base = Back Panel	Base = Back Panel
Floor mat		o	o
Operator's seat		o (Spring slide)	o (Spring slide)

ISEKI
