| Tractor Model | AT5390F E1 | AT5330F E1 | |
| Engine | Model | E3CDT (with Turbo) | E3CD |
| No. of cylinders | 3 | 3 | |
| Displacement, L | 1.498 | 1.498 | |
| Out-put Net kW(hp) | 29.85(40.0) | 25.4(34.0) | |
| Rated Engine revolution, min-1 | 2600 | ||
| Fuel Tank capacity, L | 40 | ||
| Air cleaner | Double element | ||
| Battery | 55B24R | ||
| Transmission | Main Clutch | Dry, Single | |
| Main Shift | F3/R1 | ||
| Sub Shift | 3 | ||
| No. of speed | F9/R3 | ||
| Lever Position | Main Shift | Side | |
| Sub Shift | Side | ||
| PTO | Rear PTO No. of Speed | 2 | |
| Revolution, mm-1 | 690x820 | ||
| Lever Position | Side | ||
| Travelling Speed | Forward, km/h | 1.89 - 21(24) | 1.71 - 19.8(21.7) |
| Reverse, km/h | 2.41 - 13.8 | 2.18 - 12.4(21.7) | |
| Tyre | Front | 8 - 16 | 7 - 16 |
| Rear | 13.6 - 24 | 11.2 - 24 | |
| Front Axie | Power Steering | Intergral | |
| Front Bumper | Standard | ||
| Hydraulics | Lift capacity Link et, kgf | 1,270 | |
| 24¡¨be, kgf | 1,150 | ||
| Pump capacity Main, L/min | 33.6 | ||
| Sub. L/min | 18.1 | ||
| Oil Flow, L/min | 51.7 | ||
| Position Control | Standard | ||
| Draft Control | Option | ||
| Aux. Valve | Option | ||
| 3P Linkage | Type | Cat I | |
| Couping devise | Fixed Drawbar | ||
| Electric | Head Lights | 45/40W | |
| Turning Signal/Hazard/Tall Lights | Standard | ||
| Fuel/Techno meter | Standard | ||
| Water temperature | Standard | ||
| Exterior | Floor shape | Semi Flat | |
| Floor mount | Floating mount | ||
| Floor mat | Standard | ||
| Seat | Standard(w/Spring) | ||
| Engine hood | Tilt Up | ||
| Dimensions | Overall Length, mm | 3,120(3P) | |
| Overall Width, mm | 1,455 | ||
| Overall Height, mm | 1,530(at Seat) | 1,510(at Seat) | |
| Wheel base, mm | 1,770 | ||
| Tread Front, mm | 1,150(at Seat) | 1,095 | |
| Tread Rear, mm | 1,100 | ||
| Min Ground clearance, mm | 380 | 355 | |
| Weight, kg | 1,260 | 1,230 | |
| Tractor Model | NT536 | NT540 | |
| DIMENSION | |||
| Overall length, mm | 3060 (3P) | 3060 (3P) | |
| Overall width, mm | 1455 | 1455 | |
| Overall height, mm | 1495 | 1520 | |
| Wheel base, mm | 1650 | 1650 | |
| Tread | Front, mm | 1095 | 1150 |
| Rear, mm | 1100 | 1100 | |
| Min. height from ground, mm | 375 | 400 | |
| Weight, kg | 1235 | 1260 | |
| ENGINE | |||
| Model | E3CG-D | E3CG-TD | |
| Number of cylinders | 3 | 3 | |
| Displacement, L | 1.647 | 1.647 | |
| Gross output, KW(PS) | 26.6(36.2) | 29.4(40.0) | |
| Rated speed, min-1 | 2700 | 2700 | |
| Fuel control system | Direct injection | Direct injection + Turbo Charger | |
| Fuel tank capacity, L | 43 | 43 | |
| TRANSMISSION | |||
| Main clutch | Single dry clutch | Single dry clutch | |
| Gear shift | Shuttle | Synchro shuttle | Synchro shuttle |
| Main gear speed | 4 | 4 | |
| Sub gear speed | 2 | 2 | |
| No. of speed | F8/R8 | F8/R8 | |
| Lever position | Main gear shift position | Center | Center |
| Sub gear shift position | Side | Side | |
| Synhro shuttle position | Column | Column | |
| Clutch Type | No. of speed | 2 | 2 |
| Rotation speed (min-1) | 540/750 | 540/750 | |
| PTO lever position | Side | Side | |
| REAR AXLE | |||
| Diff lock | Pedal (Right) | Pedal (Right) | |
| Braking system | Wet disc | Wet disc | |
| Brake pedal type | 2 pedal (Right) | 2 pedal (Right) | |
| Parking brake | STD (hook type) | STD (hook type) | |
| Max speed | Forward (kw/h) | 1.85-21.9(24.1) | 1.85-21.9(24.1) |
| Reverse (kw/h) | 1.7-21.5 | 1.7-21.5 | |
| TIRE | |||
| Agricultural | Front wheel | 8-16 | 8-16 |
| Rear wheel | 12.4-24 | 13.6-24 | |
| FRONT AXLE | |||
| Driving system | 4WD/2WD | 4WD/2WD | |
| Steering system | integral | integral | |
| Turning radius | 2.4 (w/B) | 2.4 (w/B) | |
| HYDRAULIC | |||
| Hydraulic power | Ball end (kgf) | 1000 | 1000 |
| 24 inches (kgf) | 810 | 810 | |
| Main (L/min) | 32.5 | 32.5 | |
| Pump discharge rate | 50 | 50 | |
| Position control | STD | STD | |
| Draft control | x | x | |
| Auxiliary hydraulic valve / Standard (Max) | Opt x2 | Opt x2 | |
| 3 POINT LINKAGE | |||
| 3P Linkage | Category | 1 | 1 |
| Lower link | Ball End | Ball End | |
| Rear hitch | Thai hitch | Thai hitch | |
| EXTERIOR | |||
| Floor | Convex floor | Convex floor | |
| Seat base | Base = Back Panel | Base = Back Panel | |
| Floor mat | o | o | |
| Operator's seat | o (Spring slide) | o (Spring slide) | |
